ASME B16.9-2018 View larger

ASME B16.9-2018

M00000175

New product

ASME B16.9-2018 Factory-Made Wrought Buttwelding Fittings

standard by ASME International, 10/29/2018

More details

In stock

$155.00

More info

Full Description

Upon request from industry and government, ASME has been defining piping safety since 1922.

This Standard covers overall dimensions, tolerances, ratings, testing, and markings for factory-made wrought buttwelding fittings in sizes NPS 1/2 through NPS 48 (DN 15 through DN 1200). It covers fittings of any producible wall thickness. This standard does not cover low pressure corrosion resistant buttwelding fittings. See MSS SP-43, Wrought Stainless Steel Butt-Welding Fittings.

Short radius elbows and returns, which were previously included in ASME B16.28-1994, are included in this standard.

B16.9 is to be used in conjunction with equipment described in other volumes of the ASME B16 series of standards as well as with other ASME standards, such as the Boiler and Pressure Vessel Code and the B31 Piping Codes.

Careful application of these B16 standards will help users to comply with applicable regulations within their jurisdictions, while achieving the operational, cost and safety benefits to be gained from the many industry best-practices detailed within these volumes.

Intended for manufacturers, owners, employers, users and others concerned with the specification, buying, maintenance, training and safe use of wrought and forged fittings with pressure equipment, plus all potential governing entities.
