ASME B29.21-2013 (R2018) View larger

ASME B29.21-2013 (R2018)

M00000467

New product

ASME B29.21-2013 (R2018) 700 Class Welded Steel and Cast Chains, Attachments, and Sprockets for Water and Sewage Treatment Plants

standard by ASME International, 01/15/2014

More details

In stock

$44.00

More info

Full Description

This Standard contains information on 700 Class cast iron, welded steel, stainless steel fabricated, and nonmetallic (plastic) chains, attachments and sprockets for water and sewage treatment plants. There are also Tables for (a) General chain dimensions, Ultimate strengths, Strand length, and Measuring load for checking chain length; minimum and maximum controlling dimensions for interchangeable chain links; (b) Chain clearance dimensions; (c) A42, F2, F22-6, F22-8, K2 and M1 attachments; (d) Pressure angle, Pitch diameter, and Clearance circle; (e) Maximum eccentricity and Face Run-out at root bottom diameter; and (f) Flange diameters for curved sidebar type chain.
