ASME B1.7-2006 (R2016) Screw Threads: Nomenclature, Definitions, and Letter Symbols

standard by ASME International, 11/17/2006

More details

In stock

$39.00

More info

Full Description

The purpose of this Standard is to establish a uniform practice for standard screw threads with regard to the following: (a) screw thread nomenclature; (b) letter symbols for designating features of a screw thread for use on drawings, in tables that set forth dimensional standards, in other records, and for expressing mathematical relationship. This Standard consists of: a glossary of terms, illustrations, an illustrated table showing the application of symbols, and a table of thread series designations. Many of the terms and symbols specified in this Standard vary considerably from those prior to the 1984 issue, because ISO terms and symbols have been adopted where the intended definition is the same.
