ASME B29.22-2001 (R2016) View larger

ASME B29.22-2001 (R2016)

M00001308

New product

ASME B29.22-2001 (R2016) Drop Forged Rivetless Chains, Sprocket Teeth Drive Chain/Drive Dogs

standard by ASME International, 09/01/2002

More details

In stock

$39.00

More info

Full Description

This Standard includes information for Drop Forged Rivetless Chains, Sprocket Teeth Drive Chain/Drive Dogs; Strand Length Tolerance; Dimensions for Chain Links; Chain Assembly; Sprocket Tooth Forms-A and B; Drive; and Drive Dogs-ANSI 160 and ISO 32A1 Drive Chains. There are also tables for Regular, X-Type, and Modified X-Type Drop Forged Rivetless Chains; Sprockets Maximum Eccentricity and Face Runout at Root Diameter; and Sprocket Factors.
