ASME B73.1-2001 (R2007) View larger

ASME B73.1-2001 (R2007)

M00001328

New product

ASME B73.1-2001 (R2007) Specification for Horizontal End Suction Centrifugal Pumps for Chemical Process

standard by ASME International, 02/01/2002

More details

In stock

$47.00

More info

Full Description

This standard covers centrifugal pumps of horizontal, end suction single stage, centerline discharge design. This Standard includes dimensional interchangeability requirements and certain design features to facilitate installation and maintenance. It is the intent of this Standard that pumps of the same standard dimension designation from all sources of supply shall be interchangeable with respect to mounting dimensions, size and location of suction and discharge nozzles, input shafts, baseplates, and foundation bolt holes (see Tables 1 and 2).
