WRC 230 View larger

WRC 230

M00002620

New product

WRC 230 Part 1: An Experimental Study of Elasto-Plastic Response of Branch-Pipe Tee Connections Subjected to Internal Pressure, External Couples and Combined Loadings

Bulletin / Circular by Welding Research Council, 1977

F. Ellyin

More details

In stock

$72.00

More info

Full Description

Experimental results of nine branch-pipe tee connections and two plain pipes are reported. The models were exposed to individual loadings: internal pressure and external couples and their combination. The loads were applied well beyond the elastic limit, and the elasto-plastic response of the models are discussed. Experimental limit or yield-point load of each model is determined, and the interaction curves are plotted. For the individual loadings, the out-of-plane couple is the critical case. However, presence of the internal pressure increases the resistance to the external couple. Normalized limit couple (out-of-plane or in-plane) decreases with the increase of diameter ratio. All models showed considerable reserve capacity beyond the experimentally determined limit loads.
